KMSW-YT1.2

Housing material:

High-strength die-cast aluminum

Ultra-clear tempered glass

Die-cast luminaire end-cap

Waterproof silicone gasket

Surface Finish :

Electrostatically applied polyester powder coat

Installation:

Non-adjustable brackets

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF:150mm two-core 0.75mm²anti-siphon cable (Power cable)

ON/OFF AC220V: 150mm three-core lmm²anti-siphon cable (Power cable)

DMX512:500mm five-core 2*1+3*0.3mm²cable (Power and signal in a cable)

DMX512 AC220V:500mm 3*1mm²+4*0.5mm²signal cable

Features Benefits:

1.Stylish design,perfect into the installation scene

2.Huge-space heat dissipation structure ensure LED stability and long-life service

3.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving.

4.Support a variety of data transmission protocols :DMX512,DMX512-RDM

5.Multibit Processing technique: Support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW/A/L mode, CMY mode and other multi-functional options

6.Optional overvoltage/overcurrent monitoring protection, temperature monitoring management,white balance management, multi-color single pass high light efficiency management, CCT/DUV/ high brightness/high color temperature management, color gray level correction management
