KMXQ-BH2.0 测试

Description Features

Housing material:

6063 aviation aluminum

Die-cast aluminum end-cap

High-strength die-cast aluminum bracket

Waterproof silicone gasket

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF/0-10V/DALl: 100mm two-core lmm² (power cable)

DMX512: 100mm five-core 2*1+3*0.3mm² (Power and signal in a cable)

Features Benefits:

1.Multibit Processing technique:Support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW/A/L mode, CMY mode and other multi-functional options Multi-funtional Accessories: Accessories for installation , glare control and blending into scenarios

2.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving

3.Full Gamut Management: RGB,RGBW/A/L/C/CLA gamut control management, up to seven colors management

4. Optional overvoltage/overcurrent monitoring, protection, temperature monitoring management,white balance management, multi-color single pass high light efficiency management, CCT/DUV/ high brightness/high color temperature management, color gray level correction management

Optical Data

Power 72W

8°	Distance (m)	1	2	4	8	10
	Max lumination (lux)	111907.3	6994.2	3108.5	1748.5	1119.0
	Halo diameter (m)	0.1	0.6	0.9	1.2	1.5
10°	Distance (m)	1	2	4	8	10
	Max lumination (lx)	61555.4	3847.2	1709.8	961.8	615.5
	Halo diameter (m)	0.2	0.8	1.1	1.5	1.9
13°	Distance (m)	1	2	4	8	10
	Max lumination (lx)	45739.9	2858.7	1270.5	714.6	457.4
	Halo diameter (m)	0.2	0.8	1.2	1.6	2.0
20°	Distance (m)	1	2	4	8	10
	Max lumination (lx)	20424.1	1276.5	567.3	319.1	204.2
	Halo diameter (m)	0.3	1.5	2.3	3.1	3.8
40°	Distance (m)	1	2	4	8	10
	Max lumination (lx)	7678.9	479.9	213.3	119.9	76.7
	Halo diameter (m)	0.7	2.8	4.2	5.6	7.0
45°	Distance (m)	1	2	4	8	10
	Max lumination (lx)	7124.3	445.2	197.9	111.3	71.2
	Halo diameter (m)	0.8	3.3	5.0	6.7	8.3
10*25°	Distance (m)	1	2	4	8	10
	Max lumination (lx)	28916.2	1807.2	803.2	451.8	289.1
	Halo diameter (m)	0.1	0.7	1.1	1.5	1.9
10*40°	Distance (m)	1	2	4	8	10
	Max lumination (lx)	17922.5	1120.1	497.8	280.0	179.2
	Halo diameter (m)	0.2	0.8	1.2	1.6	2.0

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMXT-BH2.0-TJ-24A/B4	L1000mm	72W	DC24V DC36-48V AC220V	2200K-6500K 1800K-3000K+4000K-6500K	8° / 10° / 13° / 20° / 40° / 45° / 1025° / 1040°	ON/OFF DMX512 ★★★ 0-10V DALI	CREE OSRAMS EPISTAR LUMILED SANAN
KMXT-BH2.0-TJ-12A/B2	L506mm	36W
KMXT-BH2.0-TJ-6A/B1	L300mm	18W
KMXT-BH2.0-TJ-24C4	L1000mm	72W		RGB	15° / 25° / 40° / 60° / 15*40°	DMX512 ★★★
KMXT-BH2.0-TJ-12C2	L506mm	36W
KMXT-BH2.0-TJ-6C1	L300mm	18W
KMXT-BH2.0-TJ-24D4	L1000mm	48W/72W/96W		RGBW	15° / 25° / 40° / 60° / 15*40°	DMX512 ★★★
KMXT-BH2.0-TJ-12D2	L506mm	18W/36W/48W
KMXT-BH2.0-TJ-6D1	L300mm	12W/18W/24W
