KMBD-TX 1.0 测试

Description Features

Housing material:

High-strength die-cast aluminum

Ultra-clear tempered glass

Waterproof silicone gasket

Surface Finish :

Electrostatically applied polyester powder coat

Installation:

Non-adjustable brackets

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF: 500mm two-core 0.75mm²sheathed cable (Power cable)

ON/OFF AC220V:500 three-core 0.75mm²anti-siphon cable (Power cable)

DMX512:500mm six-core 2*0.75+4*0.3mm²sheathed cable (Power and signal in a cable)

Features Benefits:

1.Stylish design, good light effect, appropriately embellish a variety of installation scenes


2.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving


3.Support a variety of data transmission protocol:DMX512


4.Multi-bit processing technology: Support brightness adjustment, built-in lighting mode setting, automatic coding

OPTICAL DATA

Power one-way 2W
8°Distance (m)11.522.53
Max lumination (lux)3412.741516.77853.18546.04379.19
Halo diameter (m)0.140.210.280.350.42
10°Distance (m)11.522.53
Max lumination (lux)1398.68621.63349.67223.79155.41
Halo diameter (m)0.200.300.410.510.61
13°Distance (m)11.522.53
Max lumination (lux)1148.15510.29287.04183.70127.57
Halo diameter (m)0.200.310.410.510.61
20°Distance (m)11.522.53
Max lumination (lux)521.87231.94130.4783.5057.99
Halo diameter (m)0.380.570.750.941.13
40°Distance (m)11.522.53
Max lumination (lux)203.4690.4350.8732.5522.61
Halo diameter (m)0.671.011.341.682.01
45°Distance (m)11.522.53
Max lumination (lux)183.6781.6345.9229.3920.41
Halo diameter (m)0.801.201.612.012.41

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMBD-TX1.0-PZ-4A100*100*68mm8W(4pcs)

AC220V

DC24V

2700K-6500K

8° / 10° / 13° / 15° / 20° / 25° / 40° / 45°

ON/OFF

CREE

OSRAMS

EPISTAR

LUMILED

SANAN

KMBD-TX1.0-PZ-4A/B8W(4pcs)

DC24V

2200K-6500K

1800K-3000K+4000K-6500K

DMX512

KMBD-TX1.0-PZ-4C6W(4pcs)

RGB

15° / 25° / 45° / 60°
KMBD-TX1.0-4D12W(4pcs)

RGBW

Dimensions

EVO Accessories

Certification/Compliance

IP66
AC220V
DC24V
JCXKPT
-40+55
10%-90%
DMX
OFF
IK07
