KMDG-Y30 测试

Description Features

Housing material:

Dustproof and anti-UV PC cover

ABS basement

Full glue filling structure

Installation:

Non-adjustable bracket

Steel wire buckle ,modular layout

Cable:

ON/OFF: 150mm two-core 1mm²(Power cable)

DMX512: 150mm five-core 2*1+3*0.3mm²(Power and signal in a cable)

Features Benefits:

1.Small size and delicate, easy to hide, perfect into the installation scene


2.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving


3.Support a variety of data transmission protocols :DMX512


4. Multi-bit processing, technology: Support brightness adjustment, built-in lighting mode setting, automatic coding

Optical Data

Power 0.72W
105°Distance (m)12345
Max lumination (lux)7.221.810.800.450.29
Halo diameter (m)2.595.187.7710.3612.95

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMDG-Y30-3A∅30*15mm0.72W(3pcs)

DC12V

1800K-6500K

105°

OFF/ON

DMX512

CREE

OSRAMS

EPISTAR

LUMILED

SANAN

KMDG-Y30-3C∅30*15mm0.72W(3pcs)

RGB

DMX512

KMDG-Y30-3D∅30*15mm0.96W(3pcs)

RGB+W

Dimensions



Other Dimensions

KMDG-Y30-GS

KMDG-Y30-LY




EVO Accessories

Certification/Compliance

IP66
DC12V
-40+55
10%-90%
JCXKPT
DMX
