KMTG-TJ3.0 测试

Description Features

Housing material:

ADC12 national standard die-cast aluminum

High strength aluminum alloy bracket

Ultra-clear tempered glass

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF 0-10V DALl :500mm two-core lmm² anti-siphon cable

ON/OFF AC220V :500mm three-core lmm² anti-siphon cable

DIX512 :500mm five-core 2*1+3*0.3mm² self-locking connectors(Power and signal in a cable)

DMX512 AC220V:500mm three-core lmm² (Anti-siphon cable ) +500mm four-core 0.5mm² self-locking connector (Signal cable)

Features Benefits:

1.Multibit Processing technique:Support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW/A/L mode, CMY mode and other multi-functional options

2.Multi-funtional Accessories: Accessories for installation , glare control and blending into scenarios

3.Full Gamut Management: RGB,RGBW/A/L/C/CLA gamut control management, up to seven colors management

4.Multibit Processing technique : Support multi-channel mode, stroboscopic,CCT color temperature adjystment,RGBW/A/L mode,CMY mode and other multi-funtional options

5.Optional overvoltage/overcurrent monitoring, protection, temperature monitoring, management, white balance management,multi-color single pass high ight efficiency management, CCT/DUV/high brightness/high color temperature management, color gray level correction management

Optical Data

Power 72W

8°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	100369.0	4014.7	1003.6	446.0	250.9
	Halo diameter (m)	0.1	0.8	1.7	2.5	3.4
10°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	55092.1	3443.2	1530.3	860.8	550.9
	Halo diameter (m)	0.2	0.8	1.2	1.6	2.1
13°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	35524.4	2220.2	986.7	555.0	355.2
	Halo diameter (m)	0.2	0.8	1.3	1.7	2.1
20°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	17775.8	4443.9	1975.1	1110.9	711.0
	Halo diameter (m)	0.4	0.8	1.2	1.6	2.0
40°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	6096.4	1524.1	677.3	381.0	243.8
	Halo diameter (m)	0.7	1.5	2.3	3.1	3.9
45°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	6084.5	1521.1	676.0	380.2	243.3
	Halo diameter (m)	0.8	1.7	2.6	3.4	4.3

Power 70W

5°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	263933.8	10557.3	2639.3	1193.0	659.8
	Halo diameter (m)	0.1	0.4	0.8	1.2	1.6
8°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	117649.0	4705.9	1176.4	522.8	294.1
	Halo diameter (m)	0.1	0.5	1.1	1.6	2.2
15°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	27830.2	1739.3	773.0	434.8	278.3
	Halo diameter (m)	0.2	1.0	1.5	2.0	2.6
25°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	12227.2	3056.8	1358.5	764.2	489.0
	Halo diameter (m)	0.3	0.7	1.1	1.5	1.9

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMTG-TJ3.0-UX-24A/B	∅221mm	72W(24pcs)	DC24V DC48V AC220V	2200K-6500K 1800K-3000K+4000K-6500K	8° / 10° / 13° / 20° / 40° / 45°	ON/OFF DMX512★★★ 0-10V DALI	CREE OSRAMS EPISTAR LUMILED SANAN
KMTG-TJ3.0-UX-7A/B	∅221mm	70W(7pcs)		2200K-6500K 1800K-3000K+4000K-6500K	5° / 8° / 15° / 25°	ON/OFF DMX512★★★ 0-10V DALI
KMTG-TJ3.0-UX-24C/D	∅221mm	72W(24pcs)		RGB RGBW	8° / 15° / 25° / 40° / 50°	DMX512★★★
KMTG-TJ3.0-UX-7C/D	∅221mm	70W(7pcs)		RGB RGBW	8° / 15° / 25°
KMTG-TJ3.0-UX-24D	∅221mm	144W(24pcs)		RGBW	8° / 15° / 25° / 40° / 50°
