KMTG-TJ1.0 测试

Description Features

Housing material:

ADC12 national standard die-cast aluminum

High strength aluminum alloy bracket

Ultra-clear tempered glass

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF 0-10V DALl :500mm two-core lmm² anti-siphon cable

ON/OFF AC220V :500mm three-core lmm² anti-siphon cable

DIX512 :500mm five-core 2*1+3*0.3mm² self-locking connectors(Power and signal in a cable)

DMX512 AC220V:500mm three-core lmm² (Anti-siphon cable ) +500mm four-core 0.5mm² self-locking connector (Signal cable)

Features Benefits:

1.Multibit Processing technique:Support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW/A/L mode, CMY mode and other multi-functional options

2.Multi-funtional Accessories: Accessories for installation , glare control and blending into scenarios

3.Full Gamut Management: RGB,RGBW/A/L/C/CLA gamut control management, up to seven colors management

4.Multibit Processing technique : Support multi-channel mode, stroboscopic,CCT color temperature adjystment,RGBW/A/L mode,CMY mode and other multi-funtional options

5.Optional overvoltage/overcurrent monitoring, protection, temperature monitoring, management, white balance management,multi-color single pass high ight efficiency management, CCT/DUV/high brightness/high color temperature management, color gray level correction management

Optical Data

Power 24W

8°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	38674.1	2417.1	1074.2	604.2	386.7
	Halo diameter (m)	0.1	0.7	1.0	1.4	1.7
10°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	21316.6	1332.2	592.1	333.0	213.1
	Halo diameter (m)	0.2	0.8	1.2	1.6	2.0
13°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	14628.6	3657.1	1625.4	914.2	585.1
	Halo diameter (m)	0.2	0.4	0.6	0.8	1.0
20°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	6717.5	1679.3	746.3	419.8	268.7
	Halo diameter (m)	0.4	0.8	1.2	1.6	2.0
40°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	2294.1	573.5	254.9	143.3	91.7
	Halo diameter (m)	0.8	1.6	2.4	3.2	4.0
45°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	2294.8	573.7	254.9	143.4	91.7
	Halo diameter (m)	0.8	1.7	2.6	3.4	4.3

Power 16W

5°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	103630.5	6476.9	2878.6	1619.2	1036.3
	Halo diameter (m)	0.1	0.3	0.4	0.6	0.8
8°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	47776.7	2986.0	1327.1	746.5	477.0
	Halo diameter (m)	0.1	0.4	0.6	0.8	1.1
15°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	10443.9	2610.9	1160.4	652.7	417.7
	Halo diameter (m)	0.2	0.5	0.8	1.0	1.3
25°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	4976.6	1244.1	552.9	311.0	199.0
	Halo diameter (m)	0.3	0.7	1.1	1.5	1.9

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMTG-TJ1.0-UX-9A/B	∅135mm	24W(9pcs)	DC24V DC48V AC220V	2200K-6500K 1800K-3000K+4000K-6500K	8° / 10° / 13° / 20° / 40° / 45°	ON/OFF DMX512★★★ 0-10V DALI	CREE OSRAMS EPISTAR LUMILED SANAN
KMTG-TJ1.0-UX-2A/B	∅135mm	16W(2pcs)		2200K-6500K 1800K-3000K+4000K-6500K	5° / 8° / 10° / 15° / 25°	ON/OFF DMX512★★★ 0-10V DALI
KMTG-TJ1.0-UX-9C/D	∅135mm	24W(9pcs)		RGB RGBW	8° / 15° / 25° / 40° / 50°	DMX512★★★
KMTG-TJ1.0-UX-2C/D	∅135mm	16W(2pcs)		RGB RGBW	8° / 15° / 25° / 40° / 50°
KMTG-TJ1.0-UX-9D	∅135mm	36W(9pcs)		RGBW	8° / 15° / 25° / 40° / 50°
