KMTG-DK2.0 测试

Description Features

Housing material:

ADC12 nationalstandard die-cast aluminum

High strength aluminum alloy bracket

Ultra-clear tempered glass

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF:300mm two-core 1mm²anti-siphon cable (Power cable)

ON/OFF AC220V: 300mm three-core lmm²anti-siphon cable (Power cable)

DMX512:300mm six-core 2*0.75+4*0.3mm²(Power and signal in a cable)

300mm five-core 5*lmm² self-locking tee cable (Power and signal in a cable)

Features Benefits:

1.Small size and delicate, easy to hide, perfect into the installation scene


2.Sustainable Design:Sturdy construction and glass surface without dust


3.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving.


4.Support a variety of data transmission protocols :DMX512


5.Multi-bit processing technology: Support brightness adjustment, built-in lighting mode setting, automatic coding

Optical Data

Power 8W
5°Distance (m)146810
Max lumination (lux)42684.52667.71185.6666.9426.8
Halo diameter (m)0.10.30.40.60.8
8°Distance (m)146810
Max lumination (lux)19436.81214.8539.9303.7194.3
Halo diameter (m)0.10.40.60.81.0
15°Distance (m)12345
Max lumination (lux)4656.81164.2517.4291.0186.2
Halo diameter (m)0.20.50.71.01.3
25°Distance (m)12345
Max lumination (lux)2180.1545.0242.2136.287.2
Halo diameter (m)0.30.71.11.41.8
Power 9W
8°Distance (m)146810
Max lumination (lux)10177.9636.1282.7159.0101.7
Halo diameter (m)0.10.60.91.21.5
10°Distance (m)146810
Max lumination (lux)4601.7287.6127.871.946.0
Halo diameter (m)0.20.81.21.62.0
13°Distance (m)12345
Max lumination (lux)3387.1846.7376.3211.7135.4
Halo diameter (m)0.20.40.60.81.0
20°Distance (m)12345
Max lumination (lux)1597.5399.4177.599.863.9
Halo diameter (m)0.40.81.221.62.0
40°Distance (m)12345
Max lumination (lux)559.9139.962.034.922.4
Halo diameter (m)1.71.52.33.123.9
45°Distance (m)12345
Max lumination (lux)553.1138.261.434.522.1
Halo diameter (m)0.81.72.53.44.2

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMTG-DK2.0-KJ-1A∅70MM*H113mm8W(1pcs)

AC220V

DC24V

2200K-6500K

5° / 8° / 15° / 25°

ON/OFF

CREE

OSRAMS

EPISTAR

LUMILED

SANAN

KMTG-DK2.0-KJ-1D∅70MM*H113mm15W(1pcs)

DC24V

RGBW

8° / 15° / 25°

ON/OFF

KMTG-DK2.0-KJ-3A∅70MM*H113mm9W(3pcs)

AC220V

DC24V

2200K-6500K

8° / 10° / 13° / 15° / 20° / 25° / 40° / 45

ON/OFF

KMTG-DK2.0-KJ-3A/B∅70MM*H113mm9W(3pcs)

DC24V

2200K-6500K

1800K-3000K+4000K-6500K

DMX512

KMTG-DK2.0-KJ-3C∅70MM*H113mm9W(3pcs)

RGB

15° / 25° / 40° / 50°

KMTG-DK2.0-KJ-3D∅70MM*H113mm12W(3pcs)

RGBW

Dimensions

Other Dimensions

KMTG-DK2.0-DC

KMTG-DK2.0-WJ

KMTG-DK2.0-GG

EVO Accessories

Certification/Compliance

IP66
AC220V
DC24V
-40+55
10%-90%
JCXKPT
DMX
OFF
IK07

Downloads

Product Instruction Downloads

KMTG-DK2.0-1W IES
