KMTG-DK1.0 测试

Description Features

Housing material:

ADC12 nationalstandard die-cast aluminum

High strength aluminum alloy bracket

Ultra-clear tempered glass

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF:300mm two-core 1mm²anti-siphon cable (Power cable)

ON/OFF AC220V: 300mm three-core lmm²anti-siphon cable (Power cable)

DMX512:300mm six-core 2*0.75+4*0.3mm²(Power and signal in a cable)

300mm five-core 5*lmm² self-locking tee cable (Power and signal in a cable)

Features Benefits:

1.Small size and delicate, easy to hide, perfect into the installation scene


2.Sustainable Design:Sturdy construction and glass surface without dust


3.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving.


4.Support a variety of data transmission protocols :DMX512


5.Multi-bit processing technology: Support brightness adjustment, built-in lighting mode setting, automatic coding

Optical Data

Power 3W
8°Distance (m)11.522.53
Max lumination (lux)4875.32166.81218.8780.0541.7
Halo diameter (m)0.10.20.20.30.4
10°Distance (m)11.522.53
Max lumination (lux)1998.1888.0499.5319.7222.0
Halo diameter (m)0.20.30.40.50.6
13°Distance (m)11.522.53
Max lumination (lux)4640.2728.9410.0262.4182.2
Halo diameter (m)0.20.30.40.50.6
20°Distance (m)11.522.53
Max lumination (lux)745.5331.3186.3119.282.8
Halo diameter (m)0.30.50.70.91.1
40°Distance (m)11.522.53
Max lumination (lux)290.6129.172.646.532.3
Halo diameter (m)0.61.01.31.62.0
45°Distance (m)11.522.53
Max lumination (lux)262.3116.665.641.929.1
Halo diameter (m)0.81.21.62.02.4

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMTG-DK1.0-LX-1A∅50MM*H92mm3W(1pcs)

AC220V

DC24V

2200K-6500K

8° / 10° / 13° / 15° / 20° / 25° / 40° / 45°

ON/OFF

CREE

OSRAMS

EPISTAR

LUMILED

SANAN

KMTG-DK1.0-LX-1A/B∅50MM*H92mm3W(1pcs)

DC24V

2200K-6500K

1800K-3000K+4000K-6500K

DMX512

KMTG-DK1.0-LX-1C∅50MM*H92mm3W(1pcs)

RGB

15° / 25° / 40° / 50°
KMTG-DK1.0-LX-1D∅50MM*H92mm5W(1pcs)

RGBW

Dimensions

Other Dimensions

KMTG-DK1.0-DC

KMTG-DK1.0-WJ

KMTG-DK1.0-GG

EVO Accessories

Certification/Compliance

IP66
AC220V
DC24V
-40+55
10%-90%
JCXKPT
DMX
OFF
IK07

Downloads

Product Instruction Downloads

KMTG-DK1.0-1W IES

Downloads
