KMTG-TJ2.1 测试

Description Features

Housing material:

High-strength die-cast aluminum

Convex ultra-clear tempered glass

Double-chamber heat dissipation structure

Waterproof silicone gasket

Surface Finish :

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation:±20°

The buried depth must be beneath the warning line

Cable:

ON/OFF:500mm two-core lmm² anti-siphon cable (Power cable)

ON/OFF AC220V: 500mm three-core lmm² anti-siphon cable (Power cable)

0-10V DALl: 500mm three-core lmm² anti-siphon cable+two-core lmm²signal cable

DMX512:500mm five-core 2*1+3*0.3mm²cable (Power and signal in a cable)

DMX512 AC220V:500mm 3*lmm² anti-siphon cable+4*0.5mm²signal cable

Features Benefits:

1.Unique convex glass design for self-cleaning

2.Stylish design ,half-buried installation,perfect into the installation scene

3.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving.

4.Support a variety of data transmission protocols :DMX512,DMX512-RDM, DALL

5.Multibit Processing technique: Support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW/A/L mode, CMY mode and other multi-functional options

6.Optional overvoltage/overcurrent monitoring protection, temperature monitoring management,white balance management, multi-color single pass high light efficiency management, CCT/DUV/ high brightness/high color temperature management, color gray level correction management

OPTICAL DATA

Power 48W

8°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	77206.98	4825.44	2144.64	1206.36	772.07
	Halo diameter (m)	0.17	0.69	1.03	1.38	1.72
10°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	42378.61	2648.66	117.18	662.17	423.79
	Halo diameter (m)	0.21	0.84	1.26	1.68	2.10
13°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	27326.49	6831.62	3036.28	1707.91	1093.06
	Halo diameter (m)	0.22	0.44	0.65	0.87	1.09
20°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	13673.74	3418.44	1519.30	854.61	546.95
	Halo diameter (m)	0.41	0.83	1.24	1.65	2.07
40°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	4689.58	1172.40	521.06	293.10	187.58
	Halo diameter (m)	0.79	1.57	2.36	3.14	3.93
45°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	4680.42	1170.11	520.05	292.53	187.22
	Halo diameter (m)	0.87	1.74	2.61	3.48	4.35

Power 32W

5°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	203026.06	12689.13	5639.61	3172.28	2030.26
	Halo diameter (m)	0.08	0.33	0.49	0.66	0.82
8°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	90499.30	5656.21	2513.87	1414.05	904.99
	Halo diameter (m)	0.11	0.45	0.67	0.89	1.12
15°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	21407.88	5351.97	2378.65	1337.99	856.32
	Halo diameter (m)	0.26	0.52	0.78	1.04	1.30
25°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	9405.61	2351.40	1045.07	587.85	376.22
	Halo diameter (m)	0.39	0.79	1.18	1.58	1.97

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMZS-TJ2.1-UX-16A/B	∅178*214mm	48W(16pcs)	DC24V DC48V AC220	2200K-6500K 1800K-3000K+4000K-6500K	8° / 10° / 13° / 20° / 40° / 45°	ON/OFF DMX512★★★ 0-10V DALI	CREE OSRAMS EPISTAR LUMILED SANAN
KMZS-TJ2.1-UX-4A/B		32W(4pcs)		2200K-6500K 1800K-3000K+4000K-6500K	5° / 8° / 15° / 25°	ON/OFF DMX512★★★ 0-10V DALI
KMZS-TJ2.1-UX-16C/D		48W(16pcs)		RGB RGBW	8° / 15° / 25° / 40° / 45°	DMX512★★★
KMZS-TJ2.1-UX-4C/D		40W(4pcs)		RGB RGBW
KMZS-TJ2.1-UX-16D		72W(16pcs)		RGBW
