KMBZ-XL1.0 测试

Description Features

Housing material:

High-strength die-cast aluminum

Ultra-clear tempered glass

Waterproof silicone gasket

Surface Finish :

Electrostatically applied polyester powder coat

Installation:

Non-adjustable brackets

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF:150mm two-core 0.75mm²(Power cable)

DMX512 :150mm five-core 2*1+3*0.3mm²cable (Power and signal in a cable)

Features Benefits:

1.Stylish design with a visor,hugging installation,perfect into the installation scene


2.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving


3.Support a variety of data transmission protocol:DMX512


4.Multi-bit processing technology: Support brightness adjustment, built-in lighting mode setting, automatic coding

OPTICAL DATA

Power 3W
8°Distance (m)11.522.53
Max lumination (lux)4875.342166.821218.84780.05541.70
Halo diameter (m)0.140.210.280.350.42
10°Distance (m)11.522.53
Max lumination (lux)1998.11888.05499.53319.70222.01
Halo diameter (m)0.200.300.410.510.61
13°Distance (m)11.522.53
Max lumination (lux)1640.22728.99410.06262.44182.25
Halo diameter (m)0.200.310.410.510.61
20°Distance (m)11.522.53
Max lumination (lux)745.53331.35186.38119.2882.84
Halo diameter (m)0.380.570.750.941.13
40°Distance (m)11.522.53
Max lumination (lux)290.66129.1872.6746.5132.30
Halo diameter (m)0.671.011.341.682.01
45°Distance (m)11.522.53
Max lumination (lux)262.39116.6265.6041.9829.15
Halo diameter (m)0.801.201.612.012.41

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMBZ-XL1.0-TJ-1A∅46*127mm3W(1pcs)

DC24V

2700K-6500K

8° / 10° / 13° / 15° / 20° / 25° / 40° / 45°

ON/OFF

CREE

OSRAMS

EPISTAR

LUMILED

SANAN

KMBZ-XL1.0-TJ-1A/B3W(1pcs)

2200K-6500K

1800K-3000K+4000K-6500K

DMX512

KMBZ-XL1.0-TJ-1C3W(1pcs)

RGB

15° / 25° / 40° / 60°
KMBZ-XL1.0-TJ-1D4W(1pcs)

RGBW

Dimensions

EVO Accessories

Certification/Compliance

IP66
DC24V
-40+55
10%-90%
DMX
OFF
JCXKPT
IK07

Downloads

Product Instruction Downloads

KMBZ-XL1.0-TJ-1W IES
