KMTG-ZQ2.0 测试

Description Features

Housing material:

ADC12 national standard die-cast aluminum

High strength aluminum alloy bracket

Ultra-clear tempered glass

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF 0-10V DALl :500mm two-core lmm² anti-siphon cable

ON/OFF AC220V :500mm three-core lmm² anti-siphon cable

DIX512 :500mm five-core 2*1+3*0.3mm² self-locking connectors(Power and signal in a cable)

DMX512 AC220V:500mm three-core lmm² (Anti-siphon cable ) +500mm four-core 0.5mm² self-locking connector (Signal cable)

Features Benefits:

1.Multibit Processing technique:Support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW/A/L mode, CMY mode and other multi-functional options

2.Multi-funtional Accessories: Accessories for installation , glare control and blending into scenarios

3.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving

4.Full Gamut Management: RGB,RGBW/A/L/C/CLA gamut control management, up to seven colors management

5.Optional overvoltage/overcurrent monitoring, protection, temperature monitoring, management, white balance management,multi-color single pass high ight efficiency management, CCT/DUV/high brightness/high color temperature management, color gray level correction management

Optical Data

Power 48W

8°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	77206.9	4825.4	2144.6	1206.3	772.0
	Halo diameter (m)	0.1	0.6	1.0	1.3	1.7
10°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	42378.6	2648.6	1177.1	662.1	423.7
	Halo diameter (m)	0.2	0.8	1.2	1.6	2.1
13°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	27326.4	6831.6	3036.2	1707.9	1093.0
	Halo diameter (m)	0.22	0.4	0.6	0.8	1.0
20°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	13673.7	3418.4	1519.3	854.6	546.9
	Halo diameter (m)	0.4	0.8	1.2	1.6	2.0
40°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	4689.5	1172.4	521.0	293.1	187.5
	Halo diameter (m)	0.7	1.5	2.3	3.1	3.9
45°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	4680.4	1170.1	520.0	292.5	187.2
	Halo diameter (m)	0.8	1.7	2.6	3.4	4.3

Power 32W

5°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	203026.06	12689.13	5639.61	3172.28	2030.26
	Halo diameter (m)	0.08	0.33	0.49	0.66	0.82
8°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	90499.30	5656.21	2513.87	1414.05	904.99
	Halo diameter (m)	0.11	0.45	0.67	0.89	1.12
15°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	21407.88	5351.97	2378.65	1337.99	856.32
	Halo diameter (m)	0.26	0.52	0.78	1.04	1.30
25°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	9405.61	2351.40	1045.07	587.85	376.22
	Halo diameter (m)	0.39	0.79	1.18	1.58	1.97

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMTG-ZQ2.0-UX-16A/B	20617280mm	48W(16pcs)	DC24V DC48V AC220V	2200K-6500K 1800K-3000K-4000K-6500K	8° / 10° / 13° / 20° / 40° / 45°	ON/OFF DMX512★★★ 0-10V DALI	CREE OSRAMS EPISTAR LUMILED SANAN
KMTG-ZQ2.0-UX-4A/B	20617280mm	32W(4pcs)		2200K-6500K 1800K-3000K-4000K-6500K	5° / 8° / 15° / 25°	ON/OFF DMX512★★★ 0-10V DALI
KMTG-ZQ2.0-UX-16C/D	20617280mm	48W(16pcs)		RGB RGBW	8° / 15° / 25° / 40° / 50°	DMX512★★★
KMTG-ZQ2.0-UX-4C/D	20617280mm	40W(4pcs)		RGB RGBW
KMTG-ZQ2.0-UX-16D	20617280mm	72W(16pcs)		RGBW
