KMGD-MD1.0

Description Features

Housing material:

High-strength die-cast aluminum

Ultra-clear tempered glass

Double layer light output design

Surface Finish :

Electrostatically applied polyester powder coat

Installation:

Non-adjustable brackets

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF:500mm two-core 1mm²  sheathed cable(Power cable)

ON/OFF AC220V: 500mm three-core 1mm²  sheathed cable(Power cable)

DMX512 :500mm six-core 2*0.75+4*0.3mm² sheathed cable (Power cable)

DMX512 :500mm five-core 2*1+3*0.3mm² (Power and signal in a cable)

Features Benefits:

1.Original design with independent intellectual property rights, unique double-layer appearance,perfect into the instalation scene


2.Double-layer Angle adjustable, suitable for a variety of installation environment


Support a variety of data transmission protocol :DMX512


Multi-bit,processing technology: Support brightness adjustment, built-in lighting mode setting,automatic coding

OPTICAL DATA

Power 4W
25*40°Distance (m)12345
Max lumination (lux)791.55197.8987.9549.4731.66
Halo diameter (m)0.440.871.311.742.18
15°Distance (m)12345
Max lumination (lux)2205.11551.28245.01137.8288.20
Halo diameter (m)0.240.480.730.971.21
25°Distance (m)12345
Max lumination (lux)1067.55266.89118.6266.7242.70
Halo diameter (m)0.450.911.361.822.27
30°Distance (m)12345
Max lumination (lux)731.04182.7681.2345.6929.24
Halo diameter (m)0.561.111.672.222.78
40°Distance (m)12345
Max lumination (lux)506.70126.6856.3031.6720.27
Halo diameter (m)0.711.422.132.843.55

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMGD-MD1.0-PZ-4AΦ160*200mm4W(4pcs)

AC220

DC24V

2200K-6500K

10° / 15° / 25° / 30° / 40° / 60°

ON/OFF

CREE

OSRAM

EPISTAR

LUMILEDS

SANAN

KMGD-MD1.0-PZ-4A/B6W(4pcs)

DC24V

2200K-6500K

1800K-3000K+4000K-6500K

DMX512

KMGD-MD1.0-PZ-4C6W(4pcs)

DC24V

RGB

15° / 25° / 45° / 60°
KMGD-MD1.0-PZ-4D8W(4pcs)

DC24V

RGBW

Dimensions

EVO Accessories

Certification/Compliance

IP66
AC220V
DC24V
-40+55
10%-90%
DMX
OFF
JCXKPT
IK07

Downloads

Product Instruction Downloads

KMGD-MD1.0 IES
