KMDG-Y50 测试

Description Features

Housing material:

Dustproof and anti-UV PC cover

ABS basement

Full glue filling structure

Installation:

Non-adjustable bracket

Steel wire buckle

Cable:

ON/OFF: 150mm two-core 1mm²(Power cable)

DMX512: 150mm five-core 2*1+3*0.3mm²(Power and signal in a cable)

Features Benefits:

1.Small size and delicate, easy to hide, perfect into the installation scene

2.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving

3.Support a variety of data transmission protocols :DMX512,DMX512-RDM

4. Multibit processing technique:support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW7A/L mode, CMY mode and other multi-functional options

5.Optional overvoltage/overcurrent monitoring protection, temperature monitoring management,whitebalance management, multi-color single pass high light eficiency management, CcT/DUV highbrightness/high color temperature management, color gray level correction management

Optical Data

Power 1.44W

105°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	14.44	3.61	1.60	0.90	0.58
	Halo diameter (m)	2.59	5.18	7.77	10.36	12.95

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMDG-Y50-6A	∅50*15mm	1.44W(6pcs)	DC24V	1800K-6500K	105°	OFF/ON DMX512★★★	CREE OSRAMS EPISTAR LUMILED SANAN
KMDG-Y50-6C		1.44W(6pcs)		RGB		DMX512★★★
KMDG-Y50-10D		2.46W(10pcs)		RGB+W		DMX512★★★
