KMZS-TJ 3.1 测试

Description Features

Housing material:

High-strength die-cast aluminum

Convex ultra-clear tempered glass

Double-chamber heat dissipation structure

Waterproof silicone gasket

Surface Finish :

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation:±20°

The buried depth must be beneath the warning line

Cable:

ON/OFF:500mm two-core lmm² anti-siphon cable (Power cable)

ON/OFF AC220V: 500mm three-core lmm² anti-siphon cable (Power cable)

0-10V DALl: 500mm three-core lmm² anti-siphon cable+two-core lmm²signal cable

DMX512:500mm five-core 2*1+3*0.3mm²cable (Power and signal in a cable)

DMX512 AC220V:500mm 3*lmm² anti-siphon cable+4*0.5mm²signal cable

Features Benefits:

1.Unique convex glass design for self-cleaning

2.Stylish design ,half-buried installation,perfect into the installation scene

3.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving.

4.Support a variety of data transmission protocols :DMX512,DMX512-RDM, DALL

5.Multibit Processing technique: Support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW/A/L mode, CMY mode and other multi-functional options

6.Optional overvoltage/overcurrent monitoring protection, temperature monitoring management,white balance management, multi-color single pass high light efficiency management, CCT/DUV/ high brightness/high color temperature management, color gray level correction management

OPTICAL DATA

Power 72W

8°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	100369.07	4014.76	1003.69	446.08	250.92
	Halo diameter (m)	0.17	0.86	1.72	2.58	3.44
10°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	55092.19	3443.26	1530.34	860.82	550.92
	Halo diameter (m)	0.21	0.84	1.26	1.68	2.10
13°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	35524.44	2220.28	986.79	555.07	355.24
	Halo diameter (m)	0.22	0.87	1.31	1.74	2.18
20°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	17775.86	4443.97	1975.10	1110.99	711.03
	Halo diameter (m)	0.41	0.83	1.24	1.65	2.07
40°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	6096.45	1524.11	677.38	381.03	243.86
	Halo diameter (m)	0.79	1.57	2.36	3.14	3.93
45°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	6084.55	1521.14	676.06	380.28	243.38
	Halo diameter (m)	0.87	1.74	2.61	3.48	4.35

Power 70W

5°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	263933.88	10557.36	2639.34	1173.04	659.83
	Halo diameter (m)	0.08	0.41	0.82	1.23	1.64
8°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	117649.09	4705.96	1176.49	522.88	294.12
	Halo diameter (m)	0.11	0.45	1.12	1.68	2.24
15°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	27830.24	1739.39	773.06	434.85	278.30
	Halo diameter (m)	0.26	1.04	1.57	2.09	2.61
25°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	12227.29	3056.82	1358.59	764.21	489.09
	Halo diameter (m)	0.39	0.79	1.18	1.58	1.97

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMZS-TJ3.1-UX-24A/B	∅236mm	72W(24pcs)	DC24V DC48V AC220	2200K-6500K 1800K-3000K+4000K-6500K	8° / 10° / 13° / 20° / 40° / 45°	ON/OFF DMX512★★★ 0-10V DALI	CREE OSRAMS EPISTAR LUMILED SANAN
KMZS-TJ3.1-UX-7A/B	∅236mm	70W(7pcs)		2200K-6500K 1800K-3000K+4000K-6500K	5° / 8° / 15° / 25°	ON/OFF DMX512★★★ 0-10V DALI
KMZS-TJ3.1-UX-24C/D	∅236mm	72W(24pcs)		RGB RGBW	8° / 15° / 25° / 40° / 50°	DMX512★★★
KMZS-TJ3.1-UX-7C/D	∅236mm	70W(7pcs)		RGB RGBW	8° / 15° / 25°
KMZS-TJ3.1-UX-24D	∅236mm	144W(24pcs)		RGBW	8° / 15° / 25° / 40° / 50°
