KMBD-ZY2.2 测试

Description Features

Housing material:

High-strength die-cast aluminum

Ultra-clear tempered glass

Waterproof silicone gasket

Surface Finish :

Electrostatically applied polyester powder coat

Installation:

Non-adjustable brackets

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF: 500mm two-core 0.75mm²sheathed cable (Power cable)

ON/OFF AC220V:500 three-core 0.75mm²anti-siphon cable (Power cable)

DMX512: 500mm six-core 2*0.75+4*0.3mm²sheathed cable (Power and signal in a cable) 500mm five-core 2*1+3*0.3mm²(Power and signal in a cable)

Features Benefits:

1.Stylish design, good light effect, appropriately embellish a variety of installation scenes


2.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving


3.Support a variety of data transmission protocol:DMX512


4.Multi-bit processing technology: Support brightness adjustment, built-in lighting mode setting, automatic coding

OPTICAL DATA

Power one-way 18W
8°Distance (m)12345
Max lumination (lux)33809.248452.313756.582113.081352.37
Halo diameter (m)0.160.320.480.650.81
10°Distance (m)12345
Max lumination (lux)16392.224098.061821.361024.51655.69
Halo diameter (m)0.210.430.640.851.07
13°Distance (m)12345
Max lumination (lux)12373.913093.481374.88773.37494.96
Halo diameter (m)0.220.440.660.881.10
20°Distance (m)12345
Max lumination (lux)5737.781434.45637.53358.61229.51
Halo diameter (m)0.400.811.211.612.02
40°Distance (m)12345
Max lumination (lux)1964.74491.19218.30122.8078.59
Halo diameter (m)0.791.582.363.153.94
45°Distance (m)12345
Max lumination (lux)1993.44498.36221.49124.5979.74
Halo diameter (m)0.851.712.563.414.26

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMBD-ZY2.2-PZ-18A135*200*185mm27W(18pcs)

AC220V

DC24V

2700K-6500K

8° / 10° / 13° / 15° / 20° / 25° / 40° / 45°

ON/OFF

CREE

OSRAMS

EPISTAR

LUMILED

SANAN

KMBD-ZY2.2-PZ-18A/B27W(18pcs)

2200K-6500K

1800K-3000K+4000K-6500K

DMX512

KMBD-ZY2.2-PZ-18C27W(18pcs)

RGB

15° / 25° / 45° / 60°
KMBD-ZY2.2-18D27W(18pcs)

RGBW

Dimensions

EVO Accessories

Certification/Compliance

IP66
AC220V
DC24V
JCXKPT
-40+55
10%-90%
DMX
OFF
IK07
