KMTG-TJ4.0 测试

Description Features

Housing material:

ADC12 national standard die-cast aluminum

High strength aluminum alloy bracket

Ultra-clear tempered glass

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF 0-10V DALl :500mm two-core lmm² anti-siphon cable

ON/OFF AC220V :500mm three-core lmm² anti-siphon cable

DIX512 :500mm five-core 2*1+3*0.3mm² self-locking connectors(Power and signal in a cable)

DMX512 AC220V:500mm three-core lmm² (Anti-siphon cable ) +500mm four-core 0.5mm² self-locking connector (Signal cable)

Features Benefits:

1.Multibit Processing technique:Support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW/A/L mode, CMY mode and other multi-functional options

2.Multi-funtional Accessories: Accessories for installation , glare control and blending into scenarios

3.Full Gamut Management: RGB,RGBW/A/L/C/CLA gamut control management, up to seven colors management

4.Multibit Processing technique : Support multi-channel mode, stroboscopic,CCT color temperature adjystment,RGBW/A/L mode,CMY mode and other multi-funtional options

5.Optional overvoltage/overcurrent monitoring, protection, temperature monitoring, management, white balance management,multi-color single pass high ight efficiency management, CCT/DUV/high brightness/high color temperature management, color gray level correction management

Optical Data

Power 120W

8°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	140516.70	5620.6	1405.1	624.5	351.2
	Halo diameter (m)	0.1	0.8	1.7	2.5	3.4
10°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	77129.0	4820.5	2142.4	1205.1	771.2
	Halo diameter (m)	0.2	0.8	1.2	1.6	2.1
13°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	49734.2	3108.3	91381.5	777.1	497.3
	Halo diameter (m)	0.2	0.8	1.3	1.7	2.1
20°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	24886.2	1555.3	691.2	388.8	248.8
	Halo diameter (m)	0.4	1.6	2.4	3.3	4.1
40°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	8535.0	2133.7	948.3	533.4	341.4
	Halo diameter (m)	0.7	1.5	2.3	3.1	3.9
45°	Distance (m)	1	2	3	4	5
	Max lumination (lux)	8518.3	2129.5	946.4	532.4	340.7
	Halo diameter (m)	0.8	1.7	2.6	3.4	4.3

Power 120W

5°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	369507.4	14780.3	3695.0	923.7	410.5
	Halo diameter (m)	0.1	0.4	0.8	1.6	2.4
8°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	164708.7	6588.3	1647.09	732.0	411.7
	Halo diameter (m)	0.1	0.5	1.1	1.6	2.2
15°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	38962.3	2435.1	1082.2	608.7	389.6
	Halo diameter (m)	0.2	1.0	1.5	2.0	2.6
25°	Distance (m)	1	4	6	8	10
	Max lumination (lux)	17118.2	1069.8	475.5	267.4	171.1
	Halo diameter (m)	0.3	1.5	2.3	13.1	3.9

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMTG-TJ4.0-UX-36A/B	∅275mm	120W(36pcs)	AC220V	2200K-6500K 1800K-3000K+4000K-6500K	8° / 10° / 13° / 20° / 40° / 45°	ON/OFF DMX512★★★ 0-10V DALI	CREE OSRAMS EPISTAR LUMILED SANAN
KMTG-TJ4.0-UX-12A/B	∅275mm	120W(12pcs)		2200K-6500K 1800K-3000K+4000K-6500K	5° / 8° / 15° / 25°	ON/OFF DMX512★★★ 0-10V DALI
KMTG-TJ4.0-UX-36C/D	∅275mm	120W(36pcs)		RGB RGBW	8° / 15° / 25° / 40° / 50°	DMX512★★★
KMTG-TJ4.0-UX-12C/D	∅275mm	120W(12pcs)		RGB RGBW	8° / 15° / 25°
KMTG-TJ4.0-UX-36D	∅275mm	240W(36pcs)		RGBW	8° / 15° / 25° / 40° / 50°
