KMXQ-BH3.0 测试

Description Features

Housing material:

6063 aviation aluminum

Die-cast aluminum end-cap

High-strength die-cast aluminum bracket

Waterproof silicone gasket

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF/0-10V/DALl: 100mm two-core lmm² (power cable)

DMX512: 100mm five-core 2*1+3*0.3mm² (Power and signal in a cable)

Features Benefits:

1.Multibit Processing technique:Support multi-channel mode, stroboscopic, CCT color temperature adjustment,RGBW/A/L mode, CMY mode and other multi-functional options Multi-funtional Accessories: Accessories for installation , glare control and blending into scenarios

2.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving

3.Full Gamut Management: RGB,RGBW/A/L/C/CLA gamut control management, up to seven colors management

4. Optional overvoltage/overcurrent monitoring, protection, temperature monitoring management,white balance management, multi-color single pass high light efficiency management, CCT/DUV/ high brightness/high color temperature management, color gray level correction management

Optical Data

Power 96W

8°	Distance (m)	1	5	10	15	20
	Max lumination (lux)	190601.8	7624.0	1906.0	847.1	476.5
	Halo diameter (m)	0.1	0.7	1.5	2.2	3.0
10°	Distance (m)	1	5	10	15	20
	Max lumination (lx)	91637.7	3665.5	916.3	407.2	229.0
	Halo diameter (m)	0.2	1.0	2.0	3.0	4.0
13°	Distance (m)	1	5	10	15	20
	Max lumination (lx)	70436.2	2817.4	704.3	313.0	176.0
	Halo diameter (m)	0.2	1.0	2.0	3.1	4.1
20°	Distance (m)	1	4	6	8	10
	Max lumination (lx)	32854.9	1314.2	328.5	513.3	328.5
	Halo diameter (m)	0.3	1.9	3.8	3.0	3.8
40°	Distance (m)	1	4	6	8	10
	Max lumination (lx)	12639.4	505.5	126.3	197.4	126.3
	Halo diameter (m)	0.6	3.3	6.6	5.3	6.6
45°	Distance (m)	1	4	6	8	10
	Max lumination (lx)	11267.7	450.7	112.6	176.0	112.6
	Halo diameter (m)	0.8	4.8	8.0	6.4	8.0
10*25°	Distance (m)	1	4	6	8	10
	Max lumination (lx)	44799.2	1791.9	447.9	699.9	447.9
	Halo diameter (m)	0.1	0.9	1.8	1.4	1.8
10*40°	Distance (m)	1	4	6	8	10
	Max lumination (lx)	26706.2	1068.2	267.0	417.2	267.0
	Halo diameter (m)	0.2	1.0	2.0	1.6	2.0

Model Information

Model	Length	Power(Pcs)	Voltage	Color Temperature	Beam Angles	Control	Chips Brand
KMXT-BH3.0-TJ-24A/B6	L1000mm	96W	DC24V AC220V	2200K-6500K 1800K-3000K+4000K-6500K	8° / 10° / 13° / 20° / 40° / 45° / 1025° / 1040°	ON/OFF DMX512 ★★★ 0-10V DALI	CREE OSRAMS EPISTAR LUMILED SANAN
KMXT-BH3.0-TJ-12A/B3	L510mm	48W	DC24V AC220V
KMXT-BH3.0-TJ-6A/B2	L346mm	32W	DC24V
KMXT-BH3.0-TJ-24A4	L1000mm	72W/96W	DC24V AC220V	2200K-6500K	8° / 10° / 13° / 20° / 40° / 45° / 1025° / 1040°
KMXT-BH3.0-TJ-12A2	L506mm	36W/48W	DC24V AC220V
KMXT-BH3.0-TJ-6A1	L300mm	12W/18W	DC24V
KMXT-BH3.0-TJ-24B4	L1000mm	72W/96W	DC24V AC220V	1800K-3000K+4000K-6500K	8° / 15° / 25° / 40° / 60° / 15*30°	DMX512 ★★★
KMXT-BH3.0-TJ-12B2	L506mm	36W/48W	DC24V AC220V
KMXT-BH3.0-TJ-6B1	L300mm	12W/18W	DC24V
KMXT-BH3.0-TJ-24C6	L1000mm	96W	DC24V AC220V	RGB	8° / 15° / 25° / 40° / 60° / 15*30°
KMXT-BH3.0-TJ-12C3	L510mm	48W	DC24V AC220V
KMXT-BH3.0-TJ-6C2	L346mm	24W	DC24V
KMXT-BH3.0-TJ-24D4	L1000mm	72W/96W/150W	DC24V AC220V	RGBW	15° / 25° / 40° / 60° / 15*40°
KMXT-BH3.0-TJ-12D2	L510mm	36W/48W/72W	DC24V AC220V
KMXT-BH3.0-TJ-6D1	L346mm	12W/18W/24W	DC24V
KMXT-BH3.0-TJ-18B/C/D6	L1000mm	72W/96W	DC24V AC220V	1800K-3000K+4000K-6500K RGB RGBW	8° / 15° / 25° / 40° / 60° / 15*30°
KMXT-BH3.0-TJ-9B/C/D3	L498mm	36W/48W	DC24V AC220V
KMXT-BH3.0-TJ-6B/C/D2	L330mm	12W/18W	DC24V
KMXT-BH3.0-TJ-24B/C/D4	L1000mm	72W/96W/150W	DC24V AC220V	1800K-3000K+4000K-6500K RGB RGBW	8° / 15° / 25° / 40° / 60° / 15*30°
KMXT-BH3.0-TJ-12B/C/D2	L506mm	36W/48W/72W	DC24V AC220V
KMXT-BH3.0-TJ-6B/C/D1	L300mm	12W/18W/24W	DC24V
