KMBD-FT2.2 测试

Description Features

Housing material:

High-strength die-cast aluminum

Ultra-clear tempered glass

Waterproof silicone gasket

Surface Finish :

Electrostatically applied polyester powder coat

Installation:

Non-adjustable brackets

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF: 500mm two-core 0.75mm²sheathed cable (Power cable)

ON/OFF AC220V:500 three-core 0.75mm²anti-siphon cable (Power cable)

DMX512: 500mm six-core 2*0.75+4*0.3mm²sheathed cable (Power and signal in a cable)500mm five-core 2*1+3*0.3mm²(Power and signalin a cable)

Features Benefits:

1.Stylish design, good light effect, appropriately embellish a variety of installation scenes


2.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving


3.Support a variety of data transmission protocol:DMX512


4.Multi-bit processing technology: Support brightness adjustment, built-in lighting mode setting, automatic coding

OPTICAL DATA

Power 18W
8°Distance (m)12345
Max lumination (lux)22261.545565.382473.501391.35890.46
Halo diameter (m)0.170.340.510.670.84
10°Distance (m)12345
Max lumination (lux)11712.732928.181301.41732.05468.51
Halo diameter (m)0.210.430.640.851.07
13°Distance (m)12345
Max lumination (lux)8953.722238.43994.86559.61358.15
Halo diameter (m)0.220.440.660.881.10
20°Distance (m)12345
Max lumination (lux)4085.111021.28453.90255.32163.40
Halo diameter (m)0.400.811.211.612.02
40°Distance (m)12345
Max lumination (lux)1515.15378.79168.3594.7060.61
Halo diameter (m)0.751.4912.242.983.73
45°Distance (m)12345
Max lumination (lux)1470.77367.69163.4291.9258.83
Halo diameter (m)0.831.662.493.324.14

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMBD-FZ2.2-PZ-12A125*175*200mm32W(12pcs)

AC220V

DC24V

2700K-6500K

8° / 10° / 13° / 15° / 20° / 25° / 40° / 45°

ON/OFF

CREE

OSRAMS

EPISTAR

LUMILED

SANAN

KMBD-FZ2.2-PZ-12A/B32W(12pcs)

2200K-6500K

1800K-3000K+4000K-6500K

DMX512

KMBD-FZ2.2-PZ-12C32W(12pcs)

RGB

15° / 25° / 45° / 60°
KMBD-FZ2.2-PZ-12D32W(12pcs)

RGBW

Dimensions

EVO Accessories

Certification/Compliance

IP66
AC220V
DC24V
JCXKPT
-40+55
10%-90%
DMX
OFF
IK07
