KMTG-YX1.0

Description Features

Housing material:

ADC12 national standard die-cast aluminum

High strength aluminum alloy bracket

Ultra-clear tempered glass

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF:300mm two-core 1mm² anti-siphon cable (Power cable)

ON/OFF AC220V: 300mm three-core 1mm² anti-siphon cable (power cable)

DMX512:300mm six-core 2*0.75+4*0.3mm² (Power and data in one cable )

300mm five-core 5*1mm² self-locking tee cable (Power and signal in a cable)

Features Benefits:

1.Small size and delicate, easy to hide, perfect into the installation scene


2.Sustainable Design:Sturdy construction and glass surface without dust


3.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving.


4.Support a variety of data transmission protocol :DMX512


5.Multi-bit processing technology: Support brightness adjustment, built-in lighting mode setting, automatic coding

Optical Data

8°Distance (m)11.522.53
Max lumination (lux)4875.342166.821218.84780.05541.70
Halo diameter (m)0.140.210.280.350.42
10°Distance (m)11.522.53
Max lumination (lux)1998.11888.05499.53319.70222.01
Halo diameter (m)0.200.300.410.510.61
13°Distance (m)11.522.53
Max lumination (lux)1640.22728.99410.06262.44182.25
Halo diameter (m)0.200.310.410.510.61
20°Distance (m)11.522.53
Max lumination (lux)745.53331.35186.38119.2882.84
Halo diameter (m)0.380.570.750.941.13
40°Distance (m)11.522.53
Max lumination (lux)290.66129.1872.6746.5132.30
Halo diameter (m)0.671.011.341.682.01
45°Distance (m)11.522.53
Max lumination (lux)262.39116.6265.6041.9829.15
Halo diameter (m)0.801.201.612.012.41

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMTG-YX1.0-DB-1A50mm*50mm*H86mm3W(1pcs)

AC220V

DC24V

2200K-6500K

8° / 10° / 13° / 20° / 40° / 45°

ON/OFF

CREE

OSRAM

EPISTAR

LUMILEDS

SANAN

KMTG-YX1.0-DB-1A/B50mm*50mm*H86mm3W(1pcs)

DC24V

2200K-6500K

1800K-3000K+4000K-6500K

DMX512

KMTG-YX1.0-DB-1C50mm*50mm*H86mm3W(1pcs)

RGB

15° / 25° / 40° / 50°
KMTG-YX1.0-DB-1D50mm*50mm*H86mm5W(1pcs)

RGBW

Dimensions

Other Dimensions

KMTG-YX1.0-DC

KMTG-YX1.0-WJ

KMTG-YX1.0-GJ



EVO Accessories

Certification/Compliance

IP66
AC220V
DC24V
-40+55
10%-90%
JCXKPT
DMX
OFF
IK07

Downloads

Product Instruction Downloads

KMTG-YX1.0 IES
