KMTG-YX2.1 测试

Description Features

Housing material:

ADC12 national standard die-cast aluminum

High strength aluminum alloy bracket

Ultra-clear tempered glass

Surface Finish:

Electrostatically applied polyester powder coat

Installation:

Luminaires Rotation: 90°

Luminaires are not allowed to be installed in low-lying water

Cable:

ON/OFF:300mm two-core lmm² anti-siphon cable (Power cable)

ON/OFF AC220V: 300mm three-core lmm² anti-siphon cable (power cable)

DMX512:300mm six-core 2*0.75+4*0.3mm² (Power and data in one cable )

300mm five-core 5*1mm² self-locking tee cable (Power and signal in a cable)

Features Benefits:

1.Small size and delicate, easy to hide, perfect into the installation scene


2.Sustainable Design:Sturdy construction and glass surface without dust


3.Wide Voltage Input:Precise electronic scheme, powerful reach and energy-saving.


4.Support a variety of data transmission protocol :DMX512


5.Multi-bit processing technology: Support brightness adjustment, built-in lighting mode setting, automatic coding

Optical Data

Power 8W
5°Distance (m)146810
Max lumination (lux)42684.582667.791185.68666.95426.85
Halo diameter (m)0.080.320.490.650.81
8°Distance (m)146810
Max lumination (lux)19436.851214.80539.91303.70194.37
Halo diameter (m)0.110.440.650.871.09
15°Distance (m)12345
Max lumination (lux)4656.831164.21517.43291.05186.27
Halo diameter (m)0.260.520.791.051.31
25°Distance (m)12345
Max lumination (lux)2180.13545.03242.24136.2687.21
Halo diameter (m)0.370.741.101.471.84
Power 10W
8°Distance (m)146810
Max lumination (lux)13966.94872.93387.97218.23139.67
Halo diameter (m)0.140.550.821.091.36
10°Distance (m)12345
Max lumination (lux)5860.911465.23651.21366.31234.44
Halo diameter (m)0.210.410.620.831.03
13°Distance (m)12345
Max lumination (lux)4790.981197.75532.33299.44191.64
Halo diameter (m)0.210.410.620.831.04
20°Distance (m)12345
Max lumination (lux)2222.15555.54246.91138.8888.89
Halo diameter (m)0.380.751.131.511.88
40°Distance (m)12345
Max lumination (lux)936.40234.10104.0458.5337.46
Halo diameter (m)0.6101.221.822.433.04
45°Distance (m)12345
Max lumination (lux)780.02195.0186.6748.7531.20
Halo diameter (m)0.811.632.443.264.07

Model Information

Model

Length

Power(Pcs)

Voltage

Color Temperature

Beam Angles

Control

Chips Brand

KMTG-YX2.1-GJ-1A70mm*70mm*H117mm8W(1pcs)

AC220V

DC24V

2200K-6500K

5° / 8° / 15° / 25°

ON/OFF

CREE

OSRAMS

EPISTAR

LUMILED

SANAN

KMTG-YX2.1-GJ-1D70mm*70mm*H117mm15W(1pcs)

DC24V

RGBW8° / 15° / 25°

DMX512

KMTG-YX2.1-GJ-4A70mm*70mm*H117mm10W(4pcs)

AC220V

DC24V

2200K-6500K

8° / 10° / 13° / 20° / 40° / 45°ON/OFF
KMTG-YX2.1-GJ-4A/B70mm*70mm*H117mm10W(4pcs)

DC24V

2200K-6500K

1800K-3000K+4000K-6500K

8° / 10° / 13° / 20° / 40° / 45°DMX512
KMTG-YX2.1-GJ-4C70mm*70mm*H117mm12W(4pcs)

DC24V

RGB

15° / 25° / 40° / 50°
KMTG-YX2.1-GJ-4D70mm*70mm*H117mm15W(4pcs)

DC24V

RGBW

15° / 25° / 40° / 50°

Dimensions

Other Dimensions

KMTG-YX2.1-DC

KMTG-YX2.1-GG

KMTG-YX2.1-WJ



EVO Accessories

Certification/Compliance

IP66
AC220V
DC24V
-40+55
10%-90%
JCXKPT
DMX
OFF
IK07

Downloads

Product Instruction Downloads

KMTG-YX2.1-1W IES
